Cyfres SD Actuator Electric yw dyfais rheoli terfynol y system addasu awtomatig. Mae'n derbyn signal analog 4-20mA a signal rheoli cyswllt ysbeidiol gan y rheolydd neu'r cyfrifiadur. Mae'n allbynnu torque neu rym, yn gweithredu'r mecanwaith addasu yn awtomatig, ac yn cwblhau'r dasg addasu awtomatig. Gall hefyd sylweddoli trosi "â llaw-awtomatig" trwy'r gweithredwr. Wrth newid i lawlyfr, defnyddir y gweithredwr i reoli'r actuator o bell. Gellir defnyddio actuator trydan chwarter tro i reoli falfiau amrywiol gydag ongl cylchdroi o 90 gradd, megis: falfiau caead, damperi, falfiau plwg, falfiau baffl, ac ati.
Data Technegol
|
Fodelith |
Allbwn trorym (Nm) |
Teithiant hamser (s) |
Cyfeiriaf mownt |
Traed Plât mownt |
Bwerau cyflanwaf |
Ngraddedig bwerau (Kw)) |
Ngraddedig cyfredol (A) |
Cychwynet cyfredol (A) |
Mhwysedd (Kg) |
|
|
Fflangio |
Siafft twll diamedrau (mm) |
Sfferig cholfachi fodelith |
||||||||
|
Fryoa-10 |
100 |
30 |
F07 |
φ20 |
SQJ-10 |
K/F |
0.025 |
0.2 |
1 |
18 |
|
Fryoa-15 |
150 |
30 |
F07 |
φ20 |
SQJ-10 |
K/F |
0.025 |
0.4 |
2 |
18 |
|
Fryas-25 |
250 |
30 |
F10 |
φ28 |
SQJ-25 |
K/F |
0.065 |
0.5 |
2.5 |
26 |
|
Frybs-60 |
600 |
30 |
F14 |
φ35 |
SQJ-60 |
K/F |
0.16 |
0.6 |
3 |
45 |
|
Frya+Rs100 |
1000 |
30 |
F12 |
φ45 |
SQJ-100 |
K/F |
0.25 |
0.7 |
3.5 |
53 |
|
Fryb+Rs160 |
1600 |
30 |
F14 |
φ60 |
SQJ-160 |
K/F |
0.4 |
1.5 |
7.5 |
108 |
|
40 |
K/F |
0.25 |
0.7 |
3.5 |
108 |
|||||
|
Fryb+Rs250 |
2500 |
30 |
F16 |
φ70 |
SQJ-250 |
K/F |
0.65 |
2.6 |
13 |
135 |
|
30 |
K/F |
0.4 |
1.1 |
5.5 |
135 |
|||||
|
Fryb+Rs400 |
4000 |
28 |
F16 |
φ70 |
SQJ-400 |
K/F |
1 |
3.5 |
17.5 |
150 |
|
40 |
K/F |
0.65 |
2.6 |
13 |
150 |
|||||
|
65 |
K/F |
0.4 |
1.1 |
5.5 |
150 |
|||||
|
Fryb+Rs600 |
6000 |
40 |
F16 |
φ75 |
Sqj-600 |
K/F |
1 |
3.5 |
17.5 |
160 |
|
65 |
K/F |
0.65 |
2.6 |
13 |
160 |
|||||
|
105 |
K/F |
0.4 |
1.1 |
5.5 |
160 |
|||||
|
Fryb+Rs800 |
8000 |
105 |
F25 |
φ75 |
Sqj-800 |
K/F |
1 |
1.5 |
7.5 |
225 |
|
Fryb+Rs1000 |
10000 |
130 |
F25 |
φ85 |
SQJ-1000 |
K/F |
1 |
1.5 |
7.5 |
225 |
|
Fryb+Rs1200 |
12000 |
130 |
F25 |
φ105 |
SQJ-1200 |
F |
1 |
1.5 |
7.5 |
225 |
|
Fryb+Rs1600 |
16000 |
130 |
F25 |
φ105 |
SQJ-1600 |
F |
2 |
2.6 |
13 |
260 |
|
Fryb+Rs2000 |
20000 |
150 |
F25 |
φ105 |
SQJ-2000 |
F |
2 |
2.6 |
13 |
260 |
|
Fryb+rs2600 |
26000 |
150 |
F25 |
φ105 |
SQJ-2600 |
F |
2 |
2.6 |
13 |
260 |
|
Fryb+Rs3000 |
30000 |
150 |
F25 |
φ105 |
SQJ-3000 |
F |
2 |
2.6 |
13 |
260 |
